Rogue Stereo 100 power amp

Price:

$3,995.00

This Rogue Audio product is built to order only

please contact us before placing your order.

Whether your tastes run to the delicate strains of the violin or the wail of the electric guitar, the Rogue Stereo 100 power amplifier will thrill you with its precision, musicality, and impact. And with 100 watts of pure tube power, you can be sure that your amplifier won’t run out of steam before the musicians do. The heart of the Stereo 100 consists of four matched KT120 output tubes operating in push-pull configuration.

Out of stock

Description

A massive fully regulated power supply ensures that low frequency information will not go unheard, and that the power and attack of transient musical passages will be recreated in full. And with a simple flip of a switch, audiophiles can choose between “pure triode” and “ultra-linear” operation to suit their tastes and power requirements. The transparency and power of the Stereo 100 is testimony to a design that truly transcends that of the competition.

While the build quality is readily evidenced in the exquisitely sculpted appearance of the Stereo 100, the beauty of this amplifier is more than just skin deep. From the Mundorf EVO Oil coupling capacitors to the custom wound output transformers, the audio signal travels through only the finest components available. With this winning combination of leading edge circuit topology, great components, and a stunning appearance, you can be certain that you are investing in an amplifier design that only Rogue Audio can deliver.

– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
General Features:
– Ultra-wide bandwidth output transformers
– Massive fully regulated high voltage supply
– Matched quad output tubes

– Heavy-duty gold plated RCA inputs

– Heavy-duty gold plated binding posts
– User selectable 4 and 8 ohm output taps
– User selectable triode or ultralinear output
– (4) KT120, (2) 12AU7, (2) 12AX7 tube complement
– Built in bias meter

– Integral tube cage
– Machined aluminum faceplate
– Mechanically isolated transformers
– Heavy (2 ounce) copper circuit board
– All precision components
– Fully tested, burned in, and auditioned
– 3 year limited warranty (6 months on tubes)

– – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – – –
Specifications:
– output power: 100 WPC minimum

– input impedance: 200K Ohms
– frequency response: 5Hz – 50KHz ± 1dB
– THD: <0.1% typ., <1.0% at rated power
– input sensitivity: 1.0V RMS
– dimensions: 18″W x 17″D x 7″H
– weight: 60 lbs.
– power requirements: 115/60Hz or 230V/50Hz

Additional information

Weight125 lbs
Dimensions17.5 × 28 × 10.25 in
Power Output per Channel

150W @ 2, 4 or 8 ohms

Number of Channels

2

Total Harmonic Distortion

0.5% maximum harmonic distortion at any power level from 250 milliwatts to rated power, 20Hz to 20kHz

S/N below rated output

112dB

Dynamic Headroom

1.2dB

Damping Factor

>18

Rated Power Band

20Hz to 20kHz

Frequency Response

+0, -0.25dB from 20Hz to 20kHz
+0, -3dB from 10Hz to 70kHZ

Speaker Binding Post Type

Patented Solid Cinch Speaker Binding Posts

Circuit Configuration

Unity Coupled

Circuit Design

Vacuum Tube

Output Type

Unity Coupled Output Transformer

Balanced Input

2

Illumination

Small Signal Tubes, Green, Blue and Natural

Chassis Style

Bead blasted black anodized aluminum with matte finish carbon fiber side panels

Dimensions

17.5" x 10.25" x 28"

Weight

125 lbs
